Yanmar 119225-52102 Fuel Pump for Yanmar
Yanmar 119225-52102 Fuel Pump. Aftermarket fuel pump supplied by Vidishi Auto. Compatible with Yanmar. MOQ 45 pieces. WhatsApp bulk pricing.
$48.00
100% Secure Checkout
Free Shipping Over $1099
Customer Satisfaction
International Shipping
Product Details
Yanmar 119225-52102 — Overview
The Yanmar 119225-52102 is an aftermarket fuel pump supplied under the Vidishi Auto brand, built as a direct-fit replacement for the reference Yanmar 119225-52102. It is a drop-in unit for the applications listed in the fitment section.
We stock this unit for wholesale, fleet and retail repair supply, with batch traceability on every order.
Fitment — Yanmar 119225-52102
Compatible with the following Yanmar applications. Always confirm the 119225-52102 by matching the OE number on the part label and the engine code on the vehicle data plate.
- Yanmar 3TNV88 / 4TNV88 / 4TNV94 / 4TNV98 diesel engines
- Yanmar 4JH4AE / 4JH5E / 4TNE88 engines
- John Deere 1023E / 1025R / 1026R / 2025R compact tractors
- Yanmar tractors, excavators and generator sets
Engine codes: Yanmar 2V750 / 2TNV70, Yanmar 3TNM68 / 3TNV70 / 3TNV76, Yanmar 4TNV84 / 4TNV88 / 4TNV94 / 4TNV98, Yanmar 4JH4AE / 4JH5E / 4TNE88 · Model years: confirm by engine model.
Specifications
| Part number | 119225-52102 |
| Product type | Fuel Pump |
| Condition | New |
| Brand | Yanmar, Vidishi Auto |
| MOQ | 45 pieces |
| Reference brand | Yanmar |
| Model years | confirm by engine model |
| Voltage | 12V (service range DC 8.5-16V) |
| Fuel Type | Diesel |
| Dimensions | 130 mm long, 50/60 mm dia, hose ID 5.9 mm |
| Type | electric solenoid feed pump (rubber-piping type) |
| Discharge | over 400 cc/min at 12V, 20C |
| Pump Head | below 37.3 kPa |
| Current | below 1.5A |
| Suction Head | -4.0 kPa |
| Temp Range | -30 to +70 C |
| Mounting | 61 mm bolt spacing |
Values shown are the published specifications for this 119225-52102. Confirm critical values against the OE part before bulk order.
Common Failure Symptoms
Before replacing, confirm the fault. Signs that point to a failing 119225-52102 fuel pump include:
- Hard starting or no start from no fuel delivery
- Loss of power under load from low feed pressure
- Engine cutting out from intermittent pump operation
- Pump noise from a failing solenoid
- Air in the fuel system from a leaking pump
These symptoms can also arise from related components, so verify the fuel pressure and electrical supply before fitting a new unit.
Installation Notes
Mount on the rubber-piping fuel line with the flow arrow in the correct direction, keep the wiring polarity correct on the 12V supply, and secure the 61 mm-spaced bracket bolts. Prime the system and check for leaks and steady delivery after fitting.
Cross Reference — 119225-52102
The 119225-52102 fuel pump is interchangeable with, and replaces, the following reference numbers:
- 119225-52102
- R1401-51350
- RC60151350
- 16851-52030
- 17121-52030
- JD002001
- 129612-52100
- AM876207
- Y119225-52102
Reference: this is a compatible replacement part supplied under the Vidishi Auto brand. It is not a genuine Yanmar product and is not sold as, or endorsed by, the original manufacturer. Trademarks are the property of their respective owners and are used only to describe compatibility.
Product Gallery
Frequently Asked Questions
Is the 119225-52102 a genuine Yanmar part?
No. It is a compatible 12V electric fuel feed pump supplied under the Vidishi Auto brand, built to replace the Yanmar 119225-52102. It is not made or endorsed by Yanmar; OEM numbers are used only to describe compatibility.
Which engines use the 119225-52102?
Yanmar TNV/TNE series diesels including 3TNV88, 4TNV88, 4TNV94, 4TNV98, 4JH4AE, 4JH5E and 4TNE88, plus John Deere compact tractors via AM876207.
What voltage and output does it have?
It runs on 12V (service range DC 8.5-16V), delivers over 400 cc/min at 12V, draws under 1.5A and develops up to about 37.3 kPa pump head.
What does the 119225-52102 replace?
It replaces 119225-52102 and cross-references R1401-51350, RC60151350, 16851-52030 and John Deere AM876207. Match by the number on your old pump.
What are the signs this fuel pump is failing?
Hard starting, loss of power under load, intermittent running, pump noise and air in the fuel lines.
How do I confirm fitment before ordering?
Send the number from your old pump and your engine model (for example 4TNV98) and we will confirm the correct variant.
Wholesale & Bulk Supply
We supply the Yanmar 119225-52102 to wholesale distributors, fleet operators and repair shops, including Yanmar. MOQ starts at 45 pieces; container and mixed orders are available.
As an aftermarket fuel pump supplier we support OEM-coded ordering, part-number matching and drop-shipment. Contact our team on WhatsApp for lead times and tiered pricing.
Applications & Search Terms
Buyers and workshops searching this unit typically use terms such as yanmar fuel pump, yanmar fuel pump overhaul, yanmar fuel pump parts, yanmar fuel pump problems, yanmar fuel pump replacement, yanmar fuel pump timing, fuel pump, fuel pump replacement cost.
Across catalogues the same unit also appears under these part numbers and search terms:
fuel pump relay, electric fuel pump, fuel pump symptoms, fuel pump control module, fuel pump fuse, fuel pump assembly, fuel pump cost replacement, fuel pump removal tool, fuel pump repair, fuel pumps, electric fuel pump for carburetor, fuel pump module, fuel pump relay replacement, fuel pump driver module, fuel pump lock ring tool, fuel pump of car
Typical applications include Yanmar John model years confirm by engine model.
Quality & Warranty
Every fuel pump is inspected before dispatch and covered by a 12-month functional warranty against manufacturing defects. Each unit is batch-traceable by part number 119225-52102.
Shipping & Handling
We ship fuel pump worldwide by air, sea and courier. MOQ 45 pieces. Standard protective packaging; fuel-system parts are drained and sealed for transport. Ask for the current lead time and freight quote on WhatsApp.
Ready to order the 119225-52102?
Send the part number 119225-52102 and your quantity for a quotation. Our team replies on WhatsApp within one business day.
Fitment Support
Not 100% sure the 119225-52102 fits? Send the VIN or the OE number from your old part and we will confirm the correct fuel pump before you order. Technical support is free.
