MW Spiral Bevel Gearbox 1:1 Speed Reducer 1450 rpm Cultivator
Spiral bevel gearbox with a 1:1 ratio and 1450 rpm input, built for cultivators and general farm machinery.
Original price was: $52.99.$49.78Current price is: $49.78.
100% Secure Checkout
Free Shipping Over $1099
Customer Satisfaction
International Shipping
Product Specifications
Product Details
Technical specifications
| Gear type | Spiral bevel reducer |
|---|---|
| Ratio | 1:1 |
| Input speed | 1450 rpm |
| Output speed | 1450 rpm |
| Output torque | Not published |
| Housing material | Magnesium-aluminium alloy |
| Mounting position | Horizontal bracket |
| Max input power | Not published |
| Net weight | 5 kg |
| Warranty | 1 year |
| Packaged shipping weight | Not published by the manufacturer |
| Packaged shipping size (L x W x H) | Not published by the manufacturer |
| Supplied brand | Vidishi Auto |
| Reference design | MW (reference only) |
| Origin status | Not a genuine MW product – aftermarket compatibility part |
What this spiral bevel gearbox does
A spiral bevel gearbox changes the direction of a drive while the curved tooth form keeps the mesh quieter and carries more load than a straight bevel set. This unit is listed at a 1:1 ratio, so the output turns at the same speed as the input, and it is rated for 1450 rpm on both shafts.
Supplied under the Vidishi Auto brand as a compatible replacement referencing MW, this unit is aimed at distributors, workshops and fleet buyers who need a repeatable, documented part.
Why choose this unit
- Spiral bevel teeth run quieter than straight bevel sets of the same size
- 1:1 ratio keeps output speed equal to input speed for transfer drives
- Magnesium-aluminium housing keeps the unit at 5 kg for light machinery
- Horizontal bracket mounting suits cultivator and frame mounted drives
- Rated for 1450 rpm on both the input and the output shaft
Compatibility & fitment
The gearbox suits cultivators and farm machinery drives where a 1:1 right-angle transfer is needed at a 1450 rpm input. Because the output speed equals the input speed, any machine that needs a speed reduction needs a different ratio, and the horizontal bracket mounting has to match the machine frame.
Confirm the input speed of your motor or PTO, the 1:1 requirement and the horizontal bracket layout. A machine needing a reduction ratio will not work correctly with this unit.
How it works
Spiral bevel teeth engage gradually rather than all at once, which spreads the load across more of the tooth face and keeps noise down. With a 1:1 ratio the gear set transfers torque at the same speed it receives it, the only change being the direction of the output shaft.
Installation steps
- Bolt the horizontal bracket to a flat frame face and tighten to the machine manual.
- Fit the coupling onto the input shaft and check the alignment with the motor.
- Fill the housing with the specified oil grade before the first run.
- Run the drive unloaded for a few minutes and listen for irregular noise.
Safety & certifications
Guards must cover the input and output shafts whenever the drive is running. The unit is listed with a 1 year warranty and a magnesium-aluminium housing, so mounting bolts should be checked regularly because light alloy castings can loosen under vibration.
Typical use cases
- Cultivator drive transfer
- Farm machinery right-angle drive
- Conveyor or auger transfer at 1:1
- Workshop test rig drive head
Wholesale & B2B supply
We supply MW Spiral Bevel Gearbox 1:1 Speed Reducer for Cultivators in wholesale quantities (MOQ 50 pieces) for distributors, workshops and fleet operators. MW, Vidishi Auto units ship in export cartons and can be OEM/ODM labelled.
Request tiered pricing for container or pallet orders, and share your target volume so we can quote MOQ-based pricing.
How it compares
Against a straight bevel set, the spiral tooth form runs quieter and carries more torque for the same size of housing. Against a worm reducer, this unit keeps a 1:1 relationship and higher efficiency, but it does not give the large speed reduction a worm set provides.
Troubleshooting
- Whining under load – check the tooth contact pattern and the oil level
- Output shaft play – inspect the output bearing and the locknut
- Bracket cracks – confirm the mounting face is flat and the bolts are even
Maintenance
- Check the oil level monthly and top up with the specified grade.
- Listen for a change in gear noise, which usually comes first from the bearings.
- Keep the housing fins clear of mud and crop so the unit can shed heat.
Frequently asked questions
Is this a genuine MW product?
No. It is supplied under the Vidishi Auto brand as a compatible replacement referencing MW. We do not claim to be an authorized MW dealer.
What exactly is the mw-spiral-bevel-gearbox-1-1?
It is a spiral bevel gearbox. The listed specification covers gear type Spiral bevel reducer, ratio 1:1, input speed 1450 rpm. Values the source did not publish are marked Not published in the specification table rather than estimated.
Can I order the mw-spiral-bevel-gearbox-1-1 wholesale?
Yes. The minimum order quantity is 50 pieces. Contact us on WhatsApp with the SKU and your quantity for tiered pricing on container or pallet orders.
What warranty comes with the mw-spiral-bevel-gearbox-1-1?
The warranty is 1 year as supplied by the published data.
How do I confirm the mw-spiral-bevel-gearbox-1-1 fits my application?
Confirm the input speed of your drive (1450 rpm) and the 1:1 ratio requirement, then check the data plate on the machine. If any point does not match, send us the details on WhatsApp and we will confirm before the order is placed.
What is included with the mw-spiral-bevel-gearbox-1-1?
The product covers the spiral bevel gearbox as photographed. Accessories shown in the images are part of the set as supplied; anything not shown is not included, and we confirm the contents with you on WhatsApp before dispatch.
What is the packaged shipping weight of the mw-spiral-bevel-gearbox-1-1?
The packaged shipping weight and carton size are not published by the manufacturer, so they are marked Not published in the specification table. We confirm the actual carton details on the quotation rather than estimating them.
How is the mw-spiral-bevel-gearbox-1-1 shipped and supported?
Units ship in export cartons suitable for mixed container loads, and technical support is available through the Vidishi Auto sales team on WhatsApp. Ask for the packing details with your quote so the freight can be costed accurately.
Warranty & support
Warranty is 1 year as supplied by the published data. Contact Vidishi Auto on WhatsApp with the SKU, the input speed and the mounting layout before ordering so the ratio can be confirmed.
Get a quote
Ready to order MW Spiral Bevel Gearbox 1:1 Speed Reducer for Cultivators (mw-spiral-bevel-gearbox-1-1)? Send the SKU and your quantity to our team.
