Cardan Shaft Universal Joint for Excavators and Loaders
Cardan Shaft Universal Joint For excavators, loaders, cranes and heavy machinery. Match part number CARDAN-UJ before ordering; wholesale supply with volume.
$140.80
100% Secure Checkout
Free Shipping Over $1099
Customer Satisfaction
International Shipping
Product Specifications
| position |
|---|
Product Details
A cardan shaft (also called a propeller shaft, drive shaft or universal joint shaft) transmits torque between two machine members whose shafts are not collinear or whose relative position changes during work – typically from the transmission or transfer-case output to a drive axle, or from an engine/gearbox PTO to a pump or attachment. Construction: a tubular shaft body carrying an end yoke (this product quotes flanged yokes) at each end that bolts to the mating companion flange; a cross-and-bearing universal joint (a spider, cross with four needle-bearing cups) at each end that allows angular misalignment while rotating; and a length-compensating slip-spline or telescoping section that lets the assembly change length as the axle or implement moves relative to the gearbox. Cardan joints appear across excavators, wheel loaders, mobile and crawler cranes, mining trucks, agricultural machinery, marine drives and metallurgical drives, wherever construction and mining equipment needs high torque at changing angles in dirty, high-vibration environments. Also known as a Hooke joint, Spicer joint or Hardy-Spicer joint
Body material is Forged alloy steel yokes and flanges (typical grades 42CrMo4, 34CrNiMo6, 40Cr, SAE 4140-4340), cold-drawn seamless steel tube body to EN 10305-1 (or welded tube), and case-hardened bearing-steel universal-joint crosses machined from DIN 17210 bearing-grade material with all four trunnion journals precision-ground. Slip splines are broached or hobbed then induction-hardened to roughly 52-62 HRC surface hardness over a tough ductile core; involute splines to DIN 5480 with typical ISO 286 IT6-IT7 tolerances. Note: one generalisation – this describes the standard industrial cardan shaft family, not a datasheet for this specific SKU.
Shopping notes: drive shaft carrier bearing replacement cost searches end well when the casting references and flange pattern are checked before checkout.
This unit is frequently shortlisted by parts departments researching drive shaft axle.
The notes above summarise what buyers typically need to know about drive shaft couplings before ordering.
Catalogue descriptions that mention drive shaft freightliner normally refer to the same driveline family documented here.
Catalogue descriptions that mention drive shaft images normally refer to the same driveline family documented here.
Catalogue descriptions that mention drive shaft photos normally refer to the same driveline family documented here.
The notes above summarise what buyers typically need to know about drive shaft yokes and flanges before ordering.
The notes above summarise what buyers typically need to know about drive shaft angle before ordering.
The notes above summarise what buyers typically need to know about drive shaft damage before ordering.
| Product type | Drive Shaft |
| Part number | CARDAN-UJ |
| Condition | New |
| Warranty | 12 Months |
| Minimum order | 1 piece |
| Fitting position | Driveline: mounted between the transmission, transfer-case output and the driven axle or pump drive, with one universal joint at each end |
| Material | Forged alloy steel yokes and flanges (typical grades 42CrMo4, 34CrNiMo6, 40Cr, SAE 4140-4340), cold-drawn seamless steel tube body to EN 10305-1 (or welded tube), and case-hardened bearing-steel universal-joint crosses machined from DIN 17210 bearing-grade material with all four trunnion journals precision-ground. Slip splines are broached or hobbed then induction-hardened to roughly 52-62 HRC surface hardness over a tough ductile core; involute splines to DIN 5480 with typical ISO 286 IT6-IT7 tolerances. Note: one generalisation – this describes the standard industrial cardan shaft family, not a datasheet for this specific SKU |
| Published specification | What CAN be stated as Verified general engineering fact about this product class: a cardan shaft is selected by compressed/installed length, continuous and peak torque, maximum articulation angle, flange diameter with its bolt count and bolt-hole circle, swing diameter, spline type and stroke, and dynamic balancing grade (commonly G16, or G6.3 for higher-spec industrial shafts, per ISO 1940-1). the fluctuation grows with the angle. Industry practice therefore keeps single-cardan operating angles to about 3-4 degrees per joint for vibration-free running, with the two end joints matching within about 1 degree and correctly phased so the first joint's variation cancels the second's; once the angle reaches the 4-12 degree band at speed, pulsing vibration appears. A double cardan joint puts two Hooke joints back to back with a centring yoke so the variations cancel, giving near-constant velocity at continuous angles of roughly 15-25 degrees and up to 30-45 degrees in specialised high-angle setups. A true CV joint (Rzeppa ball type, tripod type) keeps a genuine 1:1 velocity ratio at any angle and will articulate well past 45 degrees, but has a sealed rubber boot and lower tolerance for debris, which is why heavy construction and industrial drivelines stay with the robust, greaseable, high-torque-capacity cardan joint |
| Packaged shipping weight | Not published for this part number |
| Carton dimensions | Not published for this part number |
Supplied brand: Vidishi Auto. Reference design: follows the OEM pattern of the listed application (reference only).
